Room AnalyzerA plotted curve shows the average frequency response of the room.
“Found Room Modes” gives information about the found problems and what countermeasures to consider.
“Stimulus EQ” allows simulation of an equalized system with suggested frequency adjustments.
Frequency range: 16 – 250Hz

SpectrogramThe spectrogram is a 2D waterfall diagram which shows the room reverberation time to easily find problematic areas in the low frequency band.
Frequency range: 16 – 250Hz
Time: 0 – 250 ms

Frequency response – RTAReal Time Analyzer (RTA).
Shows the frequency response in one place, with 1/3 octave resolution.
Frequency range: 16 – 20000Hz

Frequency response – SPLFFT measurement with 2D/3D waterfall plot
Anechoic, Ambient & Raw visuell modes
Frequency range: 16 – 20000Hz
Time: 0 – 200 ms

Advanced SPL meterAccurate SPL meter with selectable average lengths and frequency weighting.
Displays continuous and maximum peak values along with selected meter averages.

Tone GeneratorTone generator with a wide choice of output signals can be used independently of
measurements. Output signals include sine wave (10-20kHz), pink noise and white noise.

RT60 reverberation time measurementUsing the RT60-standard the XTZ Room Analyzer II PRO can measure the reverberation time
in your room between 125Hz and 8kHz in octave bands, allowing you to make appropriate
adjustments in sound damping and diffusion.

Delay AlignmentThe new Delay Alignment tool is used for time alignment of sound sources. By measuring the distance from speakers and subwoofer, appropriate adjustments to your subwoofers position or phase settings can be made
