ShanLing SMT1.3 Streamer Digital Transport ( UK 230V Edition )

ShanLing SMT 1.3 : Optimized design for pure digitsl performance

The SMT1.3 is specifically designed as a streamer and digital transport, , eliminating internal conversions to deliver a pure digital signal to your extrenal DAC. Thanks to its dedicated upsampling system and FPGA-assited 12s output,it ensures optimum compatibility with a wide range of digital-to-analog converters, offering bit-perfect data transmission.

ShanLing SMT 1.3 : Modern systemdeveloped in-house

Equipped with a 64-bit Rockchip ARM Cortex processor, 4GB of RAM and 64GB of internal memory, the SMT 1.3 runs on a deeply customized Android 12 system. This streamlined user interface dacilitates access to menus, settings and playback controls, offering fluid navigation via the 5.8-inch Full HD touchscreen, or via the Eddict Controller app available and IOS and Android.

ShanLing SMT 1.3 :Enhanced used experience

The new user interface focuses on a simpler, fadster experience for accessing all the device's functions, withan optimized main menu, settings and playback controls. The reduction in the number of items displayed simultaneously and clearer headings offer a smoother, more fluid user experience.

The main menu provides immediate access and control of music playback,as well as direct access to your music library and streaming services.

ShanLing SMT 1.3 : Extended compatibility with streaming services

The SMT 1.3 natively supports streaming applications such as Spotify, Tidal, Qobuz, Apple Music , Apple Classical, Amazon Music, Presto Music and KKBox. It is also compatible with NAS, Samba (SMB), DLNA and AirPlay 2 protocols,enabling easy integration into a variety of streaming environments.

Product type

• Streamer
• Digital transport
• WiFi

Inputs

• Bluetooth
• 1x RJ45 Ethernet
• USB
• 2x USB-A (USB Audio)

Outputs

• 1x AES/EBU
• 1x BNC
• 1x Optical Toslink
• 1x Coaxial
• 1x I2S LVDS via HDMI
• 1x Ethernet RJ45 Gigabit

Connectivity

• WiFi 6 dual band 2.4G / 5G
• Bluetooth 5.3
• 1x RJ45 Ethernet Gigabit

Upsampling chip

• CT7302CL

USB interface

• XMOS XU316

Clocks

• Accusilicon

OS

• Android 12 custom

Processor

• Rockchip ARM

Touchscreen

• Sharp 1080p 4.96"

Storage

• 64Go of internal memory
• Slot SSD M.2 (SSD sold separately)

RAM

• 4Go

Max. external storage device capacity

• 2To

Supported audio formats

• DSD, DXD, APE, FLAC, WAV, AIFF/AIF, DTS, MP3, WMA, AAC, OGG, ALAC, MP2, M4A, AC3, OPUS, TAK, etc.

CUE support

•  Yes

Supported sampling rates

• USB output: PCM up to 32bit 768kHz, DSD up to DSD512
• I2S output: PCM up to 32bit 768kHz, DSD up to DSD512
• AES/EBU output: PCM up to 24bit 192kHz, DoP64
• BNC output: PCM up to 24bit 192kHz, DoP64
• Optical output: PCM up to 24bit 192kHz, DoP64
• Coaxial output: PCM up to 24bit 192kHz, DoP64

Supported network protocols

• DLNA
• AirPlay 2
• Samba (SMB)

Supported streaming applications

• Spotify
• TIDAL
• Qobuz
• Apple Music
• Apple Classical
• Amazon Music
• Presto Music
• KKBox
