Featuring an upgraded, high-quality DAC, digital inputs and a newly revamped built-in phono equalizer, the Marantz PM6007 integrated amplifier features ample connectivity and creates a realistic listening experience for the most musical sound.A World Of Marantz AwaitsThe PM6007 integrated current feedback amplifier powers 2x 45W (8 ohms RMS, 20Hz – 20kHz) to offer a refined audio experience.Meticulously And Masterfully Tuned
During the extensive tuning process, Marantz sound masters carefully refine and curate each component for optimal performance.
Wide Range Of Connectivity
Experience Hi-Res audio files exactly as intended through the following gold-plated inputs: 5 analog inputs, one coaxial input and two optical digital inputs.
An Updated Audio Experience
The newly updated, high-quality DAC AK4490 offers a cleaner sound for your enjoyment.
Current Feedback Amplifier
The Current Feedback Amplifier technology provides wide-bandwidth and high-speed sound reproduction. In combination with the high current power supply, the PM6007’s amplifier holds a large energy reserve to easily drive even the most demanding speakers. An advanced thermal compensation avoids memory distortion for clean amplification under any circumstances.Reference Quality D/A Conversion For Digital InputThe PM6007 features a new Hi-Res D/A conversion. It is equipped with a reference class AK4490 D/A converter, which provides up to 192-kHz/24-bit resolution for optimum fidelity with your Hi-Res audio file types.High Current Power Supply
The power supply supports high current, high speed Shottky Barrier Diodes and high current storage capacitors fed by a Toroidal Transformer that together provide wide dynamic range and low impedance drive capability.
Toroidal Transformer
A Toroidal Transformer has several advantages over a normal EI core transformer. The highly efficient design delivers more power compared to the same size EI core transformer. In addition, the shape of the Toroidal Transformer delivers low electromagnetic radiation and mechanical vibration for better sound quality.
CD6007 CD PLAYER Clear, dynamic CD sound
Marantz has been making top-notch CD players for decades now. The CD6007 follows in the footsteps of its acclaimed predecessors, offering warm, detailed sound. The company’s proprietary analog audio circuitry provides faster signal transfer and better transient response. A high-performance 24-bit/192kHz AK4490 digital-to-analog converter with a selectable digital filter lets you tailor its performance to your listening preference.
Enjoy All Your Favorite FilesSupports all your files through the front USB port including: WAV, MP3, AAC, WMA, FLAC HD, ALAC, AIFF and DSD files for a prism experienceVersatile Playback For All Your AudioEasily enjoy your CD and CD-R/RW collection and moreEnjoy Pristine Sound Quality
The high quality 192-kHz/24-bit D/A conversion features an AK4490 chip with two selectable digital filter and accurate system clock
Optimized Audio Reproduction
New selectable two digital filters optimize reproduction of digital music content.
Marantz HDAM Technology
Marantz developed its own discrete circuit boards to replace standard ICs. These HDAMs consist of discrete surface mount components with short mirror image L/R signal paths. These devices do exactly the same thing as the Op-Amps but outperform the regular IC Op-amps dramatically in terms of the Slew Rate and reduced noise level, resulting in more dynamic, accurate and detailed sound. In the CD6007, the proprietary HDAM-SA2 circuit improves on its previous HDAM module for a more stable power supply. The idling current stability is less influenced by power transistor temperatures to maintain sound performance even at high level output
Reference Quality D/A Conversion
The CD6007 features a new Hi-Res D/A conversion. It is equipped with a reference class AK4490 D/A converter, offering two selectable filter options, and provides up to 192-kHz/24-bit and DSD 5.6MHz resolution for optimum musical fidelity with tight bass, pleasant mids and smooth extended highs for CD playback and Hi-Res formats from USB memory stick.
High Current Power Supply
The audio power supply employs high speed, high current Shottky Barrier Diodes and new higher value current storage capacitors compared to the previous model. The size of the power supply capacitors has been increased by 120% for improved current stability and reduced AC noise during high demanding listening sessions.
High Slew Rate Op-Amp + HDAM-SA2
Compared to the CD6006, the CD6007 offers an improved and redesigned headphone amplifier section. The CD6007 inherits the exclusive Marantz HDAM-SA2 circuit with three gain settings (Low/Mid/High) for a perfect match with almost any brand of headphones for an optimal solo listening experience.
requency Response
Dynamic Range
Signal to Noise Ratio
Total Harmonic Distortion
Channel separation
Metal Front Panel
Remote Control
Power Consumption in W
Standby Consumption in W
Auto Power off
Detachable Power Cable
Maximum Dimensions (W x D x H) in inches
Weight in lbs.
